Product Details
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: RUIKAI
- Model Number: QTZ80(TC6012-8)
Feature: Tower Crane
Condition: New
Application: Building Construction
Rated Loading Capacity: 1.2 - 8T
Rated Lifting Moment: 800KN.m
Max. Lifting Load: 8 Tons
Max. Lifting Height: 180m
Span: 60m
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Ruikai
Model Number: QTZ80
Certification: ISO9001-2008
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: RUIKAI
- Model Number: QTZ80(TC6012-8)
2470(Kg)/2170(Kg)/1820(Kg) | ||||||
PZ2470 | PZ2170 | PZ1820 | ||||
60m | 14.9m | 43.0t | 5 | 1 | 1 | 16.34t |
54m | 14.9m | 42.6t | 5 | 1 | 0 | 14.52t |
48m | 14.9m | 42.1t | 5 | 0 | 0 | 12.35t |
Hoising | 30LVF | 14 | 4 | 450 | 30 | ||
40 | 3 | ||||||
60 | 2 | ||||||
80 | 1.5 | ||||||
7 | 8 | ≥450 | |||||
20 | 6 | ||||||
30 | 4 | ||||||
40 | 3 | ||||||
Trolleying | 50BT60 | 60/30/6.4(m/min) | 5/3.7/1.1 | ||||
Slewing | 3.7HR100 | 0~0.7(r/min) | 3.7×2 | ||||
Power | 380V(±10%) 50Hz | ||||||
rated power | 57.4 Kw | ||||||
